| This
is a very useful device to
automatically switch ON and OFF any electrical appliance or lights etc. at
preset times. Simply connect the appliance or lights to be controlled in the electrical Mains socket of device. Program the timer as required. The system will automatically start switching ON and OFF the appliance at preset times. You can program the timer for 8 ON/OFF programs .There are 56 settings for daily or weekly programs. Also available with Built in alarm (optional). Can be used for controlling school / offices / factory bells also for upto 8 daily or weekly ON/OFF settings Built in clock with battery backup. The device is very compact , elegantly designed and can be easily installed . Saves Electricity and increases life of appliances by running them only for exact required periods only. Ideal For : Automatically operating electrical appliances , lights or alarms etc. at preset times. Very use full for operating school / factory bells , controlling water lifting pumps , Outdoor lights control , Neon lights control , various process controls in production and many other timer applications . Also recommended for appliances or light etc. installed at remote locations which requires costly manpower and transportation expenses to switch them ON and OFF daily or on regular intervals i.e. road side signboard lighting , sirens , pump sets , street lights etc. Pl. note :Production of these timers is presently discontinued by us . For any querries Pl. contact again in September 2008 or later only . |
Socket to connect appliance Model : TM-403 for loads upto 1.5 KVA
Model : TM-1003 for loads upto 5 KVA Model : TM-503 Continuous timers for loads upto 1.5 KVA for repeatedly switching ON and OFF for upto 99 minute settings.
|
Pl. note :Production of these timers is presently discontinued by us .
For any querries Pl. contact again in September 2008 or later only .
|
SPECIFICATIONS : Relay contact : Model TM-403- 10 Amp , 220 volts ( Max Load : 1.5 KVA ) Model TM-503- 10 Amp , 220 volts ( Max Load : 1.5 KVA ) Model : TM-1003 - 40 Amp , 220V ( Max Load : 6 KVA
) Custom made solutions for 3 phase loads also possible. Query : For any further queries or business
correspondence pl mail to
|
|
